SK620
Product Features
Product Performance
*The above lifting parameters are the maximum test data in the factory, the actual lifting parameters are calibrated according to china national standard.
*The product images are for reference only. Due to the continuous improvement of technical design lifting parameters, other parameters and configurations are subject to change without notice.
| Performance Parameters | |
| Crane Model | SK620.HK |
| Rated lifting moment (t.m) | 49.70 |
| Rated lifting capacity (Kg) | 24852 |
| Boom sections (/) | 8 |
| Max. boom length (m) | 19.96 |
| Max. lifting height (m) | 24 |
| Maximum elevation (°) | 81 |
| Slewing angle (°) | ∞ |
| Outrigger span (mm) |
5660 |
| Rated flow of system (L/min) |
84 |
| Operating pressure (Mpa) |
33 |
| Deadweight(Crane) (Kg) |
6850±5% |
*The above lifting parameters are the maximum test data in the factory, the actual lifting parameters are calibrated according to china national standard.
*The product images are for reference only. Due to the continuous improvement of technical design lifting parameters, other parameters and configurations are subject to change without notice.
